Edge-Core EPS202 (4630-54PE-O-AC-F): 1G Cloud and Data Center Switch

AS4630-54PE, 48x 10/100/1000BASE-T PoE, 4x 25G SFP28 and 2x 100G QSFP28 ports, 48 PoE++ (90W) capable ports with 1560W PoE power budget with 2 PSUs, 780W with only 1 PSU operating, Broadcom Trident3.X3 ASIC, Quad-core Intel Atom C3558 CPU, dual hot

Edge-Core EPS202 (4630-54PE-O-AC-F): 1G Cloud and Data Center Switch
Edge-Core EPS202 (4630-54PE-O-AC-F): 1G Cloud and Data Center Switch
Edge-Core EPS202 (4630-54PE-O-AC-F): 1G Cloud and Data Center Switch
Edge-Core EPS202 (4630-54PE-O-AC-F): 1G Cloud and Data Center Switch
EPS202 (4630-54PE-O-AC-F)Kód:

Edge-Core

Výrobce:
36 měsícůZáruka:
Dostupnost po přihlášeníDostupnost:

Features:
  • Mid-range open networking switch with IEEE 802.3af/at/bt Type 3/4 PoE capability.
  • PoE capability able to power up enterprise, hospital, warehouse, and retail environments, interconnecting security with Wi-Fi access points, IP Phones, and IP cameras.
  • 48 x 10/100/1000BASE-T RJ-45 ports.
  • 4 x 25G SFP28 uplink ports supporting 10GbE/25GbE.
  • 2 x 100G QSFP28 stacking ports (subject to NOS implementation), also can be used as data transmission ports.
  • Supports TPM 1.2 with LPC interface.
  • Options to enable UEFI Secure Boot.
  • Full line-rate L2/L3 forwarding and switching.
  • Hot-swappable, load-sharing, redundant AC PSUs.
  • Hot-swappable 2 + 1 redundant fan trays.
  • Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of compatible open source options and commercial NOS offerings.

​

Parametry
0°C až +45°CProvozní teploty
ONIEManagement
Broadcom Trident3-X3 (348 Gbps)Typ chipsetu
90-264V AC, Modulární, RedundantníNapájení
PoE++ (60W)PoE/port
Do 19" rozvaděčeMontáž
10 Gbps optika, 100 Gbps optika, 25 Gbps optikaUplink porty (rychlost)
1 Gbps metalikaHlavní porty (rychlost)
48 a vícePočet portů (celkem)
L2, L3Pracovní vrstva
z přední strany do zadní (port-to-power)Proudění vzduchu
